| Brand Name : | Dexon |
| Model Number : | SC160FL |
| Certification : | CE, ISO9001, IALA |
| Price : | 2500-3000 |
| Payment Terms : | D/A,D/P,T/T,Western Union,MoneyGram,L/C |
| Supply Ability : | 10000/month |
| Delivery Time : | 3～10 days |
| Category | Specification | Details |
|---|---|---|
Main features | Material | Acrylic lens,ABS+PC base |
Flash Mode | 256 types(selectable) | |
Light Color | Red/Green/Yellow/White/Blue | |
Visible Range | 5–8 nautical miles | |
Daylight Threshold | Digital photosensitive, adjustable threshold | |
Ingress Protection | IP68 | |
Operating Temperature | -35°C to +60°C | |
Emission Angle | Floating Light ≥8°, Fixed Light ≥2.5° | |
Working Voltage | DC 10.5V – 14.4V | |
Parameter Loading | RS232 and onboard button | |
Solar Panel & Battery | Solar Panel | 4*7W, high-efficiency mono-solar panel |
Charging Current | Typical 400mA | |
Battery | LiFePO4 battery, capacity 640Wh | |
Continuous Operation | ≥25 days (without sun) | |
AIS AtoN | Communication | Default Mode3-SOTDMA , (FATDMA / RATDMA / SOTDMA, adjustable) |
Operating Frequency | 161.975MHz,162.025MHz (±0.5kHz) | |
Modulation Mode | GMSK / FSK | |
Transmission Power | 1W / 2W / 5W / 6W / 12.5W (configurable) | |
Average Power Consumption | ≤ 1W (continuous working mode),Low power mode ≤0.7W | |
Message Format | Supports standard AIS Message 21, 6; multiple formats selectable | |
W/D/K | Net Weight | 9.3 kg |
Dimensions | Floating Light: 240mm × 240mm × 489mm | |
Packaging Dimensions | 277mm × 281mm × 537mm | |
Installation | Meets domestic and international installation standards |
|
|
